Wraps a single precision (4-byte) floating point number and unit for storage in a DataElement. More...
#include <UShort.h>
Public Member Functions | |
| UShort (const Unit &unit, int value, bool scaleValue=true) | |
| Constructor. More... | |
| UShort (const Unit &unit, const void *binary) | |
| Constructor from binary. More... | |
| UShort * | copy () const |
| Return a pointer to a new copy. More... | |
| virtual | ~UShort () |
| Destructor. More... | |
| virtual unsigned int | toStream (OutStream &outStream) const |
| Send the data value to the indicated stream. More... | |
 Public Member Functions inherited from Int | |
| Int (const Unit &unit, int value, bool scaleValue=true) | |
| Constructor. More... | |
| Int (const Unit &unit, const void *binary) | |
| Constructor from binary. More... | |
| virtual | ~Int () |
| Destructor. More... | |
| void * | operator new (size_t size) |
| Override new. More... | |
| void | operator delete (void *p) |
| Override delete. More... | |
| virtual void | minus (const DataValue *rhs, DataValue *assignTo) const |
| Subtraction of another DataValue to yield another DataValue. More... | |
| virtual void | times (const double rhs, DataValue *assignTo) const |
| Multiplication by a double to yield another DataValue. More... | |
| virtual double | absDiff (const DataValue *rhs) const |
| Return the absolute value of this difference from another DataValue. More... | |
| virtual bool | copyTo (const Unit &unit, unsigned char &assignTo) const |
| Copy value to unsigned char. More... | |
| virtual bool | copyTo (const Unit &unit, double &assignTo) const |
| Copy value to double. More... | |
| virtual bool | copyTo (const Unit &unit, double &assignTo, unsigned int dim) const |
| Copy n-dimensional value to double. More... | |
| virtual bool | copyTo (const Unit &unit, float &assignTo) const |
| Copy value to float. More... | |
| virtual bool | copyTo (const Unit &unit, int &assignTo) const |
| Copy value to unsigned int. More... | |
| virtual int | compare (const Unit &unit, const unsigned char &compareTo) const |
| Comparison with unsigned char. More... | |
| virtual int | compare (const Unit &unit, const double &compareTo) const |
| Comparison with double. More... | |
| virtual int | compare (const Unit &unit, const float &compareTo) const |
| Comparison with float. More... | |
| virtual int | compare (const Unit &unit, const int &compareTo) const |
| Comparison with int. More... | |
| virtual int | compare (const DataValue &compareTo) const |
| Comparison with another DataValue. More... | |
| virtual bool | equals (const Unit &unit, const unsigned char &compareTo) const |
| Equality test with with unsigned char. More... | |
| virtual bool | equals (const Unit &unit, const double &compareTo) const |
| Equality test with double. More... | |
| virtual bool | equals (const Unit &unit, const float &compareTo) const |
| Equality test with float. More... | |
| virtual bool | equals (const Unit &unit, const int &compareTo) const |
| Equality test with int. More... | |
| virtual bool | equals (const DataValue &compareTo) const |
| Equality test with another DataValue. More... | |
| virtual bool | setFrom (const Unit &unit, unsigned char value) |
| set from unsigned char value More... | |
| virtual bool | setFrom (const Unit &unit, double value) |
| set from double value More... | |
| virtual bool | setFrom (const Unit &unit, float value) |
| set from float value More... | |
| virtual bool | setFrom (const Unit &unit, int value) |
| set int value More... | |
| virtual bool | setFrom (const DataValue &value) |
| set DataValue value More... | |
| virtual Str | toString (const Unit &unit) const |
| virtual void | fromBinary (const void *buffer) |
| Load the data from the a binary representation in the buffer Typically just a memcopy of the variable, though endianness may come into it. More... | |
| Public Member Functions inherited from DataValue | |
| virtual | ~DataValue () |
| Destructor. More... | |
| void | operator delete (void *p) |
| Override delete. More... | |
| virtual bool | copyTo (const Unit &unit, bool &assignTo) const |
| Copy value to bool. More... | |
| virtual bool | copyTo (DataValue &assignTo) const |
| Copy value to another dataValue. More... | |
| virtual int | compare (const Unit &unit, const bool &compareTo) const |
| Comparison with bool. More... | |
| virtual bool | equals (const Unit &unit, const bool &compareTo) const |
| Equality test with with bool. More... | |
| virtual bool | isNaN () |
| Returns true if the number is not a number. More... | |
| virtual bool | setFrom (const Unit &unit, bool value) |
| set from bool value More... | |
| virtual Str | toString () const |
| virtual size_t | getTypeSize () const |
| Returns the size of the internal storage type (i.e. sizeof(type)) More... | |
| virtual BinaryDataType | getBinaryType (void) const |
| Returns a constant (defined in BinaryDataType.h) representing the internal storage type. More... | |
| const Unit & | getUnit () const |
| const Unit & | getBaseUnit () const |
| void | setUnit (const Unit &unit) |
| void | clearType () |
Protected Member Functions | |
| UShort () | |
| Protected Empty constructor for use by DataEntry class. More... | |
| Protected Member Functions inherited from Int | |
| Int () | |
| Protected Empty constructor for use by DataEntry class. More... | |
| Protected Member Functions inherited from DataValue | |
| DataValue (const Unit &unit, const size_t &typeSize, const BinaryDataType &binaryType) | |
| Protected Constructor for abstract base class. More... | |
| DataValue (const size_t &typeSize, const BinaryDataType &binaryType) | |
| Protected unitless constructor for use via DataEntry class. More... | |
Additional Inherited Members | |
| Protected Attributes inherited from Int | |
| int | value_ |
| Protected Attributes inherited from DataValue | |
| const Unit * | unit_ |
| size_t | typeSize_ |
| size of the internal storage type (i.e. sizeof(type)) More... | |
| BinaryDataType | binaryType_ |
| constant (defined in BinaryDataType.h) representing the internal storage type More... | |
| Static Protected Attributes inherited from Int | |
| static RingBufferVoid * | MallocRing_ |
| Declared as a pointer to avoid including RingBuffer.h header here. More... | |
| static Int::StaticDestructor | StaticDestructor_ |
| Static instance of StaticDestructor. More... | |
Detailed Description
Wraps a single precision (4-byte) floating point number and unit for storage in a DataElement.
(Storage is in the most canonical form of the specified unit). Provides methods for reading and writing the value to and from other DataValues, performing unit conversions as needed.
Unlike the Int class, UShort objects are serialized as 2-byte numbers by throwing away the 16 least-significant bits of the significand. Thus, the resulting number has the range of a regular 4-byte float, but with only 2.5 decimal digits accuracy. Such numbers would be adequate for storing scaled measurements from an 8-bit A/D, for example.
Note: since these DataValues are created and destructed frequently, the new and delete operators have been overridden, so that objects can be re-used as needed.
UShort::MallocRing_ stores deleted objects.
Constructor & Destructor Documentation
| UShort::UShort | ( | const Unit & | unit, |
| int | value, | ||
| bool | scaleValue = true |
||
| ) |
Constructor.
Constructor for non-array storage.
References DataValue::binaryType_, DataValue::typeSize_, and USHORT2.
| UShort::UShort | ( | const Unit & | unit, |
| const void * | binary | ||
| ) |
Constructor from binary.
References DataValue::binaryType_, Int::fromBinary(), DataValue::typeSize_, and USHORT2.
|
inlinevirtual |
Destructor.
|
protected |
Protected Empty constructor for use by DataEntry class.
Protected Empty constructor for use bya DataEntry class.
References DataValue::binaryType_, DataValue::typeSize_, and USHORT2.
Referenced by copy().
Member Function Documentation
|
virtual |
Return a pointer to a new copy.
Reimplemented from Int.
References DataValue::unit_, UShort(), and Int::value_.
|
virtual |
Send the data value to the indicated stream.
Return the number of bytes written. For now, assume little-endian.
Reimplemented from Int.
References OutStream::bytesWritten(), Int::value_, and OutStream::writeShort().
The documentation for this class was generated from the following files:
- /Volumes/ubuntu_share/lrauv-application/Source/data/UShort.h
- /Volumes/ubuntu_share/lrauv-application/Source/data/UShort.cpp
